6800 Series

Bearing No.	Boundary Dimensions(mm)				Basic Load Rating		Balls		Limiting Speed		Net Weight
	Boundary Dimensions(mm)				Basic Load Rating		Balls		Limiting Speed		Net Weight
	d	D	B	Chamfer	C(N)	CO(N)	Qty	Size	Grease	Oil	Kgs
685	5	11	3	0.2	0.715	0.282	8	1.588	35000	45000	0.0011
686	6	13	3.5	0.2	1.08	0.44	8	2	33000	42000	0.0019
687	7	14	3.5	0.2	1.17	0.51	9	2	31000	40000	0.0021
688	8	16	4	0.3	1.26	0.585	9	2.381	29000	38000	0.0031
689	9	17	4	0.3	1.72	0.82	11	2	28000	36000	0.0032
6800	10	19	5	0.5	1.83	0.925	9	2.381	26000	34000	0.005
6801	12	21	5	0.5	1.92	1.04	12	2.381	22000	30000	0.006
6802	15	24	5	0.5	2.08	1.26	14	2.381	20000	28000	0.007
6803	17	26	5	0.5	2.81	1.72	15	2.381	19000	26000	0.008
6804	20	32	7	0.5	4	2.47	13	3.5	17000	22000	0.019
6805	25	37	7	0.5	4.3	2.95	15	3.5	15000	19000	0.022
6806	30	42	7	0.5	4.7	3.65	19	3.175	13000	17000	0.026
6807	35	47	7	0.5	4.9	4.05	20	3.5	11000	15000	0.029
6808	40	52	7	0.5	5.1	4.4	22	3.5	9000	13000	0.033
6809	45	58	7	0.5	6.4	5.65	22	3.969	7000	11000	0.04
6810	50	65	7	0.5	6.6	6.1	24	3.969	5000	9000	0.052
